ADG1413YRUZ by Analog Devices Inc.

The ADG1413YRUZ is a high-performance, quad single-pole single-throw (SPST) switch from Analog Devices Inc., designed to deliver exceptional signal integrity and robustness in various applications. This component is part of the industry-leading range of switch and multiplexer products that Analog Devices offers, known for their reliability and precision.

Constructed with Analog Devices' proprietary iCMOS® (industrial CMOS) technology, the ADG1413YRUZ provides an optimal balance between power consumption and performance. It operates with a single supply voltage ranging from +12 V to +30 V or a dual supply from ±5 V to ±22 V, making it versatile for both single-ended and differential signal applications.

The ADG1413YRUZ features four independently selectable switches, each with low on-resistance typically around 1.5 Ω, ensuring minimal signal distortion and power loss. This low on-resistance is matched with an on-resistance flatness of less than 0.4 Ω, which is beneficial for maintaining signal fidelity across the entire analog signal range.

Additionally, the device boasts a high current carrying capability of up to 1.5 A continuous current per channel, and it can handle peak currents of 2 A for short durations. This makes the ADG1413YRUZ an excellent choice for applications that require switching of higher current signals without compromising performance.

The switch also includes robust ESD (Electrostatic Discharge) protection, withstanding up to 2 kV human body model, which enhances its durability and longevity in harsh environments. It also features fast switching times (t_ON and t_OFF) of typically 30 ns and 20 ns, respectively, which is critical for applications requiring high-speed operation.

With its extended temperature range from -40°C to +125°C, the ADG1413YRUZ is suitable for automotive and industrial applications. The compact TSSOP (Thin Shrink Small Outline Package) package ensures that the switch can be integrated into space-constrained designs without sacrificing performance.

In summary, the ADG1413YRUZ by Analog Devices Inc. is a highly reliable and efficient solution for designers looking to incorporate a high-quality switch into their systems. Its robust performance, coupled with the versatility of its power supply requirements and packaging, makes it a go-to choice for a wide range of applications.
