Analog Devices Inc. ADG508FBRWZ Multiplexer Overview

The ADG508FBRWZ is a high-performance CMOS analog multiplexer from Analog Devices Inc., featuring 8 channels and a single-ended configuration. This device offers exceptional signal accuracy and low power operation, making it an ideal choice for precision data acquisition systems, process control, and instrumentation applications.

Key Features

• Channel Configuration: The ADG508FBRWZ provides an 8:1 multiplexer configuration, allowing for the selection of one of eight inputs to be passed to the output.
• Low On Resistance: With a typical on resistance of just 35 ohms, the device ensures minimal signal attenuation and distortion, maintaining signal integrity.
• Single Supply Operation: It operates on a single supply voltage range of 10.8 V to 16.5 V or dual supplies of ±10.8 V to ±16.5 V, offering flexibility in various circuit designs.
• Low Power Consumption: The ADG508FBRWZ's CMOS construction ensures low power dissipation, preserving energy in battery-powered devices.
• Break-Before-Make Switching: This feature prevents momentary shorting when switching between channels, protecting the device and the signal path.
• ESD Protection: The device includes enhanced electrostatic discharge protection for increased robustness in harsh environments.
• Wide Operating Temperature Range: With an operating temperature range of -40°C to +85°C, the multiplexer performs reliably across various environmental conditions.

Applications

• Data Acquisition Systems
• Test Equipment
• Process Control
• Instrumentation
• Avionics

Enclosed in a compact 16-lead wide body SOIC package, the ADG508FBRWZ is designed for space-constrained applications while still offering the high-quality performance expected from Analog Devices Inc. Its robust design and versatile features make it a go-to component for engineers looking to integrate a reliable multiplexer into their electronic designs.

For detailed technical specifications, application circuits, and additional information, designers are encouraged to refer to the official datasheet provided by Analog Devices Inc.
