ADG734BRUZ - High-Performance 4-Channel Multiplexer

The ADG734BRUZ is a monolithic CMOS device comprising four independently selectable single-pole, double-throw (SPDT) switches, manufactured by Analog Devices Inc., a leader in high-performance semiconductors for signal processing applications. This high-performance chip is designed for 2.5 V to 5.5 V single-supply operation, making it suitable for a wide range of applications in the industrial, communication, and consumer sectors.

Key Features

• Low Voltage Operation: Operates from a single 2.5 V to 5.5 V supply, ensuring compatibility with low voltage systems and enabling battery-powered device applications.
• Low On Resistance: Features a low on resistance of 4 ohms typical, providing efficient signal switching with minimal signal attenuation.
• High Bandwidth: Offers a high bandwidth (>200 MHz), making it ideal for audio and video signal routing.
• Low Power Consumption: Consumes less than 0.1 µW of power in standby mode, contributing to energy-saving designs.
• Fast Switching Times: t_ON of 20 ns and t_OFF of 10 ns allow for quick signal switching, suitable for high-speed applications.

Applications

The ADG734BRUZ is versatile and can be used in various applications such as:

• Audio and Video Signal Routing
• Communication Systems
• Data Acquisition Systems
• Relay Replacement
• Automotive Infotainment

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality and reliability. The ADG734BRUZ is no exception and is built to meet high industry standards, ensuring long-term performance in critical applications. It is available in a compact TSSOP-16 package, allowing for efficient use of PCB space.

Ordering Information

To place an order or request samples of the ADG734BRUZ, visit the Analog Devices Inc. website or contact an authorized distributor. Ensure you have the correct part number, ADG734BRUZ, to avoid any confusion with similar products.
