Manufactured by Analog Devices Inc., the ADM3054BRWZ-RL7 is a high-performance, isolated Controller Area Network (CAN) transceiver that ensures robust communication in demanding industrial and automotive environments. This transceiver facilitates the connection of a CAN protocol controller to the physical two-wire CAN bus without compromising on signal integrity and timing precision.

Key Features

• Isolation: The device features Analog Devices Inc.'s iCoupler® technology, providing 2.5 kV RMS isolated signal communication for 1 minute per UL 1577.
• Data Rates: Supports CAN data rates up to 1 Mbps, making it suitable for high-speed communication.
• Protection: The ADM3054BRWZ-RL7 is designed with overvoltage protection on the CAN bus pins up to ±30 V.
• Extended Temperature Range: Operates reliably over an industrial temperature range of -40°C to +125°C, accommodating a variety of harsh environments.
• Package: Available in a 16-lead, wide-body SOIC package, ensuring compatibility with standard PCB layouts.
• EMC Compliance: Meets the requirements of EN 50081 and EN 50082 for electromagnetic compatibility, ensuring reliable operation in electrically noisy environments.

Applications

The ADM3054BRWZ-RL7 is ideal for use in applications requiring high voltage isolation and robustness, such as:

• Industrial control and automation
• Automotive networks
• Building automation
• Heavy machinery control systems

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality. The ADM3054BRWZ-RL7 transceiver is built with the same attention to detail, ensuring reliable performance and longevity in the field. It is a testament to the company's dedication to delivering superior products that meet the stringent requirements of industrial and automotive applications.
