ADP1708ACPZ-R7

Part No ADP1708ACPZ-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 1A 8LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 5V
Dropout Voltage-Max 0.6V @ 1A
Output Current 1A
Operating Supply Current 390μA to 1.55mA
PSRR 70dB to 56dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 0.8 V to 5 V
Voltage - Dropout (Typical) 0.345V @ 1A
Mounting SMD (SMT)
Case / Package 8-LFCSP-WD (3x3)
Win Source Part Number 077650-ADP1708ACPZ-R7
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ADP1708ACPZ-R7 CAD Model

Description

The ADP1708ACPZ-R7 is a high-performance, low-dropout linear regulator offered by Analog Devices Inc., a leading company in the field of high-performance analog technology. This regulator is designed to provide a stable and reliable power supply for a wide range of applications, including portable and battery-powered devices, microprocessors, and other sensitive electronic equipment.

Key Features

  • Output Voltage: The device can deliver a fixed output voltage that is factory-set, ranging from 1.2 V to 5.0 V, which covers the common voltages required for digital circuits.
  • High Accuracy: The ADP1708ACPZ-R7 offers excellent accuracy with a low dropout voltage, ensuring that the output remains stable even when the input voltage is very close to the output voltage.
  • Current Capacity: It can provide up to 1A of output current, making it suitable for a wide range of power needs.
  • Low Quiescent Current: The device features a low quiescent current, which is ideal for battery-powered applications where conserving power is crucial.
  • Thermal Protection: It includes thermal overload protection, which helps to safeguard the device and the application in the event of an over-temperature condition.
  • Package: The regulator is available in a compact LFCSP (Lead Frame Chip Scale Package) that is suitable for space-constrained applications.

Applications

  • Portable and battery-powered devices
  • Microprocessors, microcontrollers, and DSPs
  • Data storage systems
  • Wireless infrastructure
  • Medical and healthcare equipment

The ADP1708ACPZ-R7 is not just a reliable power solution but also a testament to Analog Devices Inc.'s commitment to providing high-quality, innovative products that meet the evolving needs of technology. Its robust feature set ensures that it can be integrated into a variety of sophisticated electronic systems, delivering consistent performance and extending the life of the application it powers.
