ADP7118ACPZN-R7

Part No ADP7118ACPZN-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LIN POS ADJ 200MA 6LFCSP / Linear Voltage Regulator IC Positive Adjustable 1 Output 200mA 6-LFCSP-UD (2x2)
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Voltage Regulators - Linear
Mfr Analog Devices Inc.
Package Tape & Reel
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 20V
Voltage - Output (Min/Fixed) 1.2V
Voltage - Output (Max) 19.58V
Voltage Dropout (Max) 0.42V @ 200mA
Current - Output 200mA
Current - Quiescent (Iq) 140 µA
Current - Supply (Max) 320 µA
PSRR 88dB ~ 50dB (10kHz ~ 1MHz)
Control Features Enable, Soft Start
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 6-UDFN Exposed Pad, CSP
Supplier Device Package 6-LFCSP-UD (2x2)
Base Product Number ADP7118
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names ADP7118ACPZN-R7CT,505-ADP7118ACPZN-R7CT,ADP7118ACPZN-R7DKR,-2735-ADP7118ACPZN-R7,ADP7118ACPZN-R7-ND,-2735-ADP7118ACPZN-R7DKR,505-ADP7118ACPZN-R7TR,-2735-ADP7118ACPZN-R7CT,-2735-ADP7118ACPZN-R7-ND,ADP7118ACPZN-R7TR,ADP7118ACPZN-R7DKR-ND,505-ADP7118ACPZN-R7DKR,ADP7118ACPZN-R7CT-ND,ADP7118ACPZN-R7TR-ND
Standard Package 3,000
Win Source Part Number 977008-ADP7118ACPZN-R7
Ultra Librarian 3D Model Ultra Librarian ADP7118ACPZN-R7 CAD Model

Description

The ADP7118ACPZN-R7 is a high-performance linear voltage regulator manufactured by Analog Devices Inc., one of the leading companies in the semiconductor industry. This device is designed to provide a stable output voltage with low noise and high accuracy, making it ideal for sensitive RF or analog circuitry that requires a clean power supply.

Key Features

  • Output Voltage Range: The ADP7118ACPZN-R7 offers a wide range of output voltages, which can be adjusted from 1.2V to 20V to suit a variety of applications.
  • High Output Accuracy: With an output voltage accuracy of ±1%, this regulator ensures precise voltage delivery for critical applications.
  • Low Dropout Voltage: The device features a low dropout voltage, which enhances efficiency by allowing operation closer to the input voltage.
  • Low Noise Performance: This regulator is specifically designed to minimize output noise, a crucial feature for RF and precision analog systems.
  • High PSRR (Power Supply Rejection Ratio): High PSRR of the ADP7118ACPZN-R7 ensures stable output voltage despite variations in the input supply.
  • Thermal Overload Protection: The device includes built-in thermal overload protection that safeguards it from damage due to excessive power dissipation.
  • Current Limiting: It also features current limiting to protect the regulator and the load from overcurrent conditions.

Applications

The ADP7118ACPZN-R7 is versatile and can be used in a wide range of applications including:

  • Portable and battery-powered equipment
  • High-end audio and video applications
  • Data acquisition systems
  • Medical and healthcare devices
  • Telecommunications infrastructure
  • Automotive electronics

With its robust feature set and reliable performance, the ADP7118ACPZN-R7 from Analog Devices Inc. is a top choice for designers looking for a linear voltage regulator that meets stringent power requirements while maintaining energy efficiency and precision.
