ADP7142ACPZN-R7

Part No ADP7142ACPZN-R7
Manufacturer Analog Devices Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LIN POS ADJ 200MA 6LFCSP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 38 Weeks
Features Linear Voltage Regulator IC Positive Adjustable Output 200mA 6-LFCSP-UD (2x2)
Manufacturer Analog Devices Inc.
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package 6-UDFN Exposed Pad, CSP
Case / Package 6-LFCSP-UD (2x2)
Family Name ADP7142
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number ADP7142ACPZN-R7CT, ADP7142ACPZN-R7-ND, ADP7142ACPZN-R7TR, ADP7142ACPZN-R7DKR
Quantity per package 3000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 860351-ADP7142ACPZN-R7
Ultra Librarian 3D Model Ultra Librarian ADP7142ACPZN-R7 CAD Model

Description

ADP7142ACPZN-R7 Linear Regulator from Analog Devices Inc.

The ADP7142ACPZN-R7 is a high-performance linear regulator offered by Analog Devices Inc., a leading company in the field of high-performance analog, mixed-signal, and digital signal processing integrated circuits. This regulator is designed to provide precision, low noise, and high power supply rejection ratio (PSRR) which makes it suitable for sensitive RF or audio applications as well as medical and instrumentation equipment.

This device operates over a wide input voltage range from 4.5 V to 20 V and is capable of delivering up to 200 mA of output current. The output voltage is adjustable from 1.2 V to 12 V, which allows for flexibility in various design applications. Additionally, the ADP7142ACPZN-R7 features a low dropout voltage, ensuring efficient operation even when the input voltage is close to the output voltage, thus improving battery life in portable applications.

One of the key features of the ADP7142ACPZN-R7 is its low output noise, which is typically 9 μV rms in the 10 Hz to 100 kHz range. This low noise performance, combined with a high PSRR of 70 dB at 10 kHz, makes this regulator an excellent choice for powering noise-sensitive circuits such as precision analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and high-end audio amplifiers.

The ADP7142ACPZN-R7 is available in a compact 8-lead LFCSP (Lead Frame Chip Scale Package) which is designed for space-constrained applications. It also includes several protective features such as overcurrent protection, thermal overload protection, and reverse battery protection which help to ensure the longevity and reliability of both the regulator and the system it is used in.

Moreover, the ADP7142ACPZN-R7 supports a wide temperature range from -40°C to +125°C, making it suitable for industrial and automotive applications where extreme temperatures are common. With its combination of performance, flexibility, and protection features, the ADP7142ACPZN-R7 from Analog Devices Inc. stands out as an excellent choice for designers looking to optimize their power management solutions.
