Product Overview

The ADSP-2171BS-104 is a high-performance digital signal processor (DSP) from the renowned manufacturer Analog Devices Inc. Designed to cater to a wide range of applications, this DSP integrates advanced features that enable efficient and rapid processing of complex digital signal algorithms.

Key Features

• High-Speed Processing: With a core processing speed of 40 MIPS (Million Instructions Per Second), the ADSP-2171BS-104 is built to handle demanding signal processing tasks with ease.
• On-Chip Memory: It comes equipped with 16K bytes of on-chip RAM, allowing for quick data access and reducing the need for external memory components.
• Flexible Peripheral Options: This DSP includes a variety of peripherals, such as serial ports, parallel ports, and timer/counters, providing versatile interfacing options with other digital systems.
• Low Power Consumption: Optimized for power-sensitive applications, the ADSP-2171BS-104 maintains a balance between performance and power efficiency.
• Easy Integration: The processor is available in a 52-pin MQFP (Metric Quad Flat Pack) package, making it convenient to integrate into a wide range of electronic assemblies.

Applications

The ADSP-2171BS-104 is ideal for applications that require high-speed digital signal processing, including but not limited to:

• Audio and video processing
• Telecommunications
• Instrumentation and control systems
• Medical imaging
• Automotive electronics

Technical Specifications

For more detailed information, datasheets, and support, visit the Analog Devices Inc. website.
