The LTC6993CS6-1#TRMPBF is a versatile TimerBlox timer from Analog Devices Inc., designed to provide precision timing capabilities in a compact and easy-to-use package. This device is part of the LTC6993 series, which are monolithic, one-shot timers that can be configured for a wide range of applications, including delay, pulse width modulation, and frequency division.

Key Features

• Adjustable Timing: The LTC6993-1 variant offers an adjustable delay range from 1µs to 33.6 seconds, allowing for precise control over timing intervals.
• Accuracy: Boasting a frequency accuracy of 1.5% and a timer error of 2.65% max, this device ensures reliable and consistent timing for critical applications.
• Supply Voltage: It operates on a supply voltage ranging from 2.25V to 5.5V, making it suitable for a variety of low-voltage applications.
• Low Power Consumption: The LTC6993CS6-1#TRMPBF features a low power consumption, with only 55µA at 2.5V, which is ideal for battery-powered and portable devices.
• Output Drive: The timer can drive up to 20mA, allowing it to interface directly with a wide range of components such as relays, solenoids, and LEDs.
• Temperature Range: It is designed to operate over a temperature range of -40°C to 125°C, ensuring functionality in diverse environments.

Applications

The LTC6993CS6-1#TRMPBF is a versatile component that can be used in various applications, including but not limited to:

• System Reset and Power Management
• Frequency Discrimination
• Time Delay Generation
• Pulse Width Modulation
• Precision Pulse Generation

Package and Quality

This device comes in a compact SOT-23 package, which is ideal for space-constrained applications. It is also available in a tape and reel format under the part number LTC6993CS6-1#TRMPBF, facilitating automated manufacturing processes. Additionally, as with all Analog Devices components, this timer is manufactured to high-quality standards, ensuring reliability and performance in your electronic designs.
