Same model may have multiple batches, images only for reference.

SDR1030-6R8M

Get a Quote

Part No	SDR1030-6R8M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SDR1030-6R8M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SDR1030
Package	Tape & Reel (TR)
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	6.8 µH
Tolerance	±20%
Current Rating (Amps)	2.2 A
Current - Saturation (Isat)	2.8A
Shielding	Unshielded
DC Resistance (DCR)	52mOhm Max
Q @ Freq	15 @ 7.96MHz
Frequency - Self Resonant	38.1MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)	0.130" (3.30mm)
Base Product Number	SDR1030
Standard Package	1,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1274623-SDR1030-6R8M
Ultra Librarian 3D Model	Ultra Librarian SDR1030-6R8M CAD Model

Alternative Products

Description

The Bourns Inc. SDR1030-6R8M is a fixed inductor that is suitable for use in SMD (SMT) mounting.

Type: Drum core, wirewound
Inductance: 6.8 µH
Tolerance: ±20%
Core Material: Ferrite
DC Resistance (DCR): 52mOhm Max
Dimension: 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height: 0.130" (3.30mm)
Operating Temperature: -40°C ~ 125°C
Current Rating: 2.2 A
Package: 1,000 inductors
