Same model may have multiple batches, images only for reference.

SRP1250-R50M

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP1250-R50M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP1250-R50M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP1250
Package	Tape & Reel (TR),Cut Tape (CT)
Type	Drum Core, Wirewound
Material - Core	Iron
Inductance	500 nH
Tolerance	±20%
Current Rating (Amps)	36 A
Current - Saturation (Isat)	55A
Shielding	Shielded
DC Resistance (DCR)	1.5mOhm Max
Temperature Range - Operating	-55°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max)	0.232" (5.90mm)
Base Product Number	SRP1250
Other Names	-SRP1250-R50MCT,-SRP1250-R50M,SRP1250-R50M,SRP1250-R50MTR,-SRP1250-R50M,-SRP1250-R50MTR,SRP1250R50M,SRP1250-R50MCT
Standard Package	500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1274051-SRP1250-R50M
Ultra Librarian 3D Model	Ultra Librarian SRP1250-R50M CAD Model

Alternative Products

Description

The SRP1250-R50M is a shielded fixed inductor from Bourns Inc. with an inductance of 500 nH and a tolerance of ±20%.

Core Material: Iron
Temperature Range: -55°C to 150°C
DC Resistance: 1.5mOhm Max
Current Rating: 36 A
Height: 0.232" (5.90mm)
Dimension: 0.547" L x 0.531" W (13.90mm x 13.50mm)
Package: Tape and Reel and Cut Tape
Standard Package: 500 Units
Core Type: Drum Core, Wirewound
Applications: Power Supplies, DC-DC Converters, and EMI Filtering
