Same model may have multiple batches, images only for reference.

SRR0735A-101M

Name: SRR0735A-101M
Brand: Bourns Inc.
SKU: 1273738
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRR0735A-101M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRR0735A-101M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRR0735A
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	100 µH
Tolerance	±20%
Current Rating (Amps)	540 mA
Current - Saturation (Isat)	600mA
Shielding	Shielded
DC Resistance (DCR)	630mOhm Max
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.287" L x 0.287" W (7.30mm x 7.30mm)
Height - Seated (Max)	0.146" (3.70mm)
Base Product Number	SRR0735A
Other Names	SRR0735A-101M,SRR0735A-101MTR,SRR0735A-101MCT,SRR0735A-101MDKR
Standard Package	1,500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273738-SRR0735A-101M
Ultra Librarian 3D Model	Ultra Librarian SRR0735A-101M CAD Model

Alternative Products

Description

The Bourns Inc. SRR0735A-101M is a drum core, wirewound fixed inductor that is ideal for use in inductors, coils, chokes.

Package: tape & reel
Mounting: SMD (SMT)
Inductance: 100 µH
Tolerance: ±20%
AEC-Q200: Rated
Maximum DC Resistance: 630mOhm
Operating Temperature Range: -40°C to 125°C
Quantity per standard package: 1,500
HTSUS: 8504.50.4000
