Same model may have multiple batches, images only for reference.

PM42S-101-RC

Name: PM42S-101-RC
Brand: Bourns Inc.
SKU: 748300
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PM42S-101-RC
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	FIXED IND 100UH 400MA 1.35OHM SM
Datasheet	PM42S-101-RC Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Bourns Inc.
Series	PM42S
Package	Tape & Reel
Product Status	Active
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	100 µH
Tolerance	±30%
Current Rating (Amps)	400 mA
Current - Saturation (Isat)	300mA
Shielding	Shielded
DC Resistance (DCR)	1.35Ohm Max
Q @ Freq	10 @ 796kHz
Frequency - Self Resonant	12MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max)	0.118" (3.00mm)
Base Product Number	PM42S
Standard Package	1,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
California Prop 65	Warning Information
Win Source Part Number	748300-PM42S-101-RC
Ultra Librarian 3D Model	Ultra Librarian PM42S-101-RC CAD Model

Alternative Products

Description

The PM42S-101-RC is a surface mountable fixed inductor with a drum core, wirewound construction.

Inductance: 100µH
Tolerance: ±30%
Designed for use in: various applications, including power supplies, automotive electronics, and communication equipment
Size: 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height: 0.118" (3.00mm)
Shielded: providing excellent electromagnetic interference (EMI) suppression
DC Resistance: 1.35Ohm Max
Current Rating: 400mA
Operating Temperature Range: -40°C to 125°C
Status: active
Manufacturer: Bourns Inc.
Compliance: REACH regulations
Warning: California Prop 65
