TIC263M-S Bourns Inc.
Same model may have multiple batches, images only for reference.

TIC263M-S

Part No TIC263M-S
Manufacturer Bourns Inc.
Catalog Triacs
Description TRIAC 600V 25A SOT93 / TRIAC 600V 175A 3-Pin(3+Tab) SOT-93
Datasheet
TIC263M-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Bourns Inc.
Packaging Tube
Part Status Obsolete(EOL)
Triac Type Standard
Voltage - Off State 600V
Current - On State (It (RMS)) (Maximum) 25A
Voltage - Gate Trigger (Vgt) (Maximum) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 175A @ 50Hz
Current - Gate Trigger (Igt) (Maximum) 50mA
Current - Hold (Ih) (Maximum) 40mA
Configuration Single
Operating Temperature Range -40°C ~ 110°C (TC)
Mounting Style Through Hole
Package TO-218-3
Manufacturer Package SOT-93
Win Source Part Number 796776-TIC263M-S
Popularity Medium
Supply and Demand Status Limited
Family Name TIC263M
Introduction Date May 23, 1993
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian TIC263M-S CAD Model

Description

The TIC263M-S triac, designed by Bourns Inc., is a single configuration device.

  • Operating Temperature Range: -40°C to 110°C
  • Off-State Voltage: 600V
  • Non-Repetitive Surge Current: 175A @ 50Hz
  • Current On State: 25A (maximum)
  • Voltage Gate Trigger: 2V
  • Current Gate Trigger: 50mA (maximum)
  • Hold Current: 40mA (maximum)
  • Package: TO-218-3
  • Packaging: Tube
  • Status: Obsolete (EOL)
  • Alternative Parts: BCR16RM-12LB, BCR25RM-12LB#B01, BCR16RM-12LB#B00, BCR25RM-12LB#B00
  • Supply and Demand Status: Limited
