AT-41511-TR1G Real Image AT-41511-TR1G real image2104
Same model may have multiple batches, images only for reference.
AT-41511-TR1G Real Image AT-41511-TR1G real image2104
AT-41511-TR1G Real Image AT-41511-TR1G real image2104
Same model may have multiple batches, images only for reference.

AT-41511-TR1G

Part No AT-41511-TR1G
Manufacturer Broadcom Limited
Catalog RF Transistors (BJT)
Description IC TRANS NPN GP BIPOLAR SOT-143
Datasheet
AT-41511-TR1G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Obsolete(EOL)
Transistor Polarity NPN
VCEO Maximum Collector-Emitter Breakdown Voltage 12V
Noise Figure (dB Typ @ f) 1dB to 1.7dB @ 900MHz to 2.4GHz
Gain 11dB to 15.5dB
Maximum Power Dissipation 225mW
Typical Gain (hFE) (Min) 30 @ 5mA, 5V
Maximum Current Collector 50mA
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-143
Win Source Part Number 010320-AT-41511-TR1G
Family Name AT-41511
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Malaysia, Thailand
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automotive, Sensing & Instrumentation, Signal Processing, Consumer Electronics
Ultra Librarian 3D Model Ultra Librarian AT-41511-TR1G CAD Model

Description

Product Overview

The AT-41511-TR1G is a high-performance, general-purpose microwave transistor. Its robust design and wide frequency range make it ideal for various applications in the RF domain.

Features and Benefits

  • Wide Frequency Range: Operates efficiently from DC to 6 GHz.
  • High Gain: Provides a typical gain of 12 dB.
  • Low Noise Figure: Minimized noise levels for clearer signal transmission.
  • High Reliability: Rugged construction ensures durability and long operational life.

Applications

  • Wireless Communication Systems
  • RF and Microwave Amplification
  • Satellite Communication Systems
  • Radar Systems

Additional Details

The AT-41511-TR1G's compact SOT-363 package makes it easy to integrate into existing designs, emphasizing efficiency and performance. Its exceptional linearity and low distortion make it suitable for demanding transmission requirements.
