HCNW4503-500E Real Image HCNW4503-500E Real Image1 HCNW4503-500E Real Image2 HCNW4503-500E Real Image3
Same model may have multiple batches, images only for reference.
HCNW4503-500E Real Image HCNW4503-500E Real Image1 HCNW4503-500E Real Image2 HCNW4503-500E Real Image3
HCNW4503-500E Real Image HCNW4503-500E Real Image1 HCNW4503-500E Real Image2 HCNW4503-500E Real Image3
Same model may have multiple batches, images only for reference.

HCNW4503-500E

Part No HCNW4503-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 5KV TRANS 8DIP GULL WING
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 15% @ 16mA
Switching Turn-On and Turn-Off Time 1μs, 1μs (Max)
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.68V
Continuous forward current- Max 25mA
Temperature Range - Operating -55°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 016818-HCNW4503-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 750
Ultra Librarian 3D Model Ultra Librarian HCNW4503-500E CAD Model

Description

The Broadcom Limited 016818-HCNW4503-500E is a DC input type Transistor output type isolator with 5000Vrms isolation voltage.

  • Package: Reel-TR
  • Mounting: SMD (SMT)
  • Market Status: High popularity, balanced supply and demand
  • DC Current Transfer Ratio (Min): 15% @ 16mA
  • Output Voltage (Max): 20V
  • Channel Output Current: 8mA
  • Continuous Forward Current (Max): 25mA
