HCPL-7800A-300E

Part No HCPL-7800A-300E
Manufacturer Broadcom Limited
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP ISOLATION 100KHZ 8DIPGW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Amplifier Type Isolation
Number of Circuits 1
-3db Bandwidth 100kHz
Current - Input Bias 500nA
Voltage - Input Offset 300μV
Operating Supply Current 10.9mA
Channel Output Current 16mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 040460-HCPL-7800A-300E
Family Name HCPL-7800A
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-7800A-300E CAD Model

Description

The HCPL-7800A-300E is a high-speed optocoupler for isolation amplifiers, current sensing, and motor control applications.

  • Circuit Count: Single
  • -3dB Bandwidth: 100kHz
  • Amplifier Type: Isolation
  • Input Bias Current: 500nA
  • Input Offset Voltage: 300μV
  • Package: 8-DIP Gull Wing
  • Operating Temperature: -40°C to 85°C
