Same model may have multiple batches, images only for reference.
HSMS-2810-TR1G Broadcom Limited HSMS-2810-TR1G Real Image HSMS-2810-TR1G label picture 2 HSMS-2810-TR1G real image HSMS-2810-TR1G real image 2 HSMS-2810-TR1G real image4628 HSMS-2810-TR1G Real Image1 HSMS-2810-TR1G Real Image2 HSMS-2810-TR1G Real Image3
HSMS-2810-TR1G Broadcom Limited HSMS-2810-TR1G Real Image HSMS-2810-TR1G label picture 2 HSMS-2810-TR1G real image HSMS-2810-TR1G real image 2 HSMS-2810-TR1G real image4628 HSMS-2810-TR1G Real Image1 HSMS-2810-TR1G Real Image2 HSMS-2810-TR1G Real Image3
Same model may have multiple batches, images only for reference.

HSMS-2810-TR1G

Part No HSMS-2810-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE SCHOTTKY GP LN 20V SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - Single
Voltage - Peak Reverse (Max) 20V
Current - Max 1A
Capacitance @ Vr, F 1.2pF @ 0V, 1MHz
Resistance @ If, F 15 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 017051-HSMS-2810-TR1G
Family Name HSMS-2810
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HSMS-2810-TR1G CAD Model

Description

The HSMS-2810-TR1G from Broadcom Limited is a Schottky single diode.

  • Maximum Current: 1A
  • Peak Reverse Voltage: 20V
  • Capacitance: 1.2pF @ 0V, 1MHz
  • Resistance: 15 Ohm @ 5mA, 1MHz
  • Package: SOT-23-3
  • Operating Temperature: 150°C (TJ)
  • Quantity per Package: 3k pcs
