HSMS-2815-TR1G Broadcom Limited HSMS-2815-TR1G label picture
Same model may have multiple batches, images only for reference.
HSMS-2815-TR1G Broadcom Limited HSMS-2815-TR1G label picture
HSMS-2815-TR1G Broadcom Limited HSMS-2815-TR1G label picture
Same model may have multiple batches, images only for reference.

HSMS-2815-TR1G

Part No HSMS-2815-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE SCHOTTKY GP LN 20V SOT-143
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 2 Independent
Voltage - Peak Reverse (Max) 20V
Current - Max 1A
Capacitance @ Vr, F 1.2pF @ 0V, 1MHz
Resistance @ If, F 15 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-143-4
Win Source Part Number 017054-HSMS-2815-TR1G
Family Name HSMS-2815
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HSMS-2815-TR1G CAD Model

Description

The HSMS-2815-TR1G Schottky diode from Broadcom Limited.

  • Package: SOT-143-4
  • Maximum Current: 1A
  • Resistance: 15 Ohm @ 5mA, 1MHz
  • Capacitance: 1.2pF @ 0V, 1MHz
  • Voltage Peak Reverse: 20V
  • Packaging: Reel (3k pcs)
