MGA-81563-TR1G Real Image MGA-81563-TR1G Real Image1 MGA-81563-TR1G Real Image2 MGA-81563-TR1G Real Image3
Same model may have multiple batches, images only for reference.
MGA-81563-TR1G Real Image MGA-81563-TR1G Real Image1 MGA-81563-TR1G Real Image2 MGA-81563-TR1G Real Image3
MGA-81563-TR1G Real Image MGA-81563-TR1G Real Image1 MGA-81563-TR1G Real Image2 MGA-81563-TR1G Real Image3
Same model may have multiple batches, images only for reference.

MGA-81563-TR1G

Part No MGA-81563-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP MMIC GAAS 3V SOT-363
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 100MHz to 6GHz
P1dB 14.8dBm (30.2mW)
Gain 12.3dB
Noise Figure 2.7dB
RF Type ISM, PCS, PHS, SATCOM, WLL
Supply Voltage - Operating 2.7 V to 3.3 V
Operating Supply Current 31mA to 51mA
Test Frequency 2GHz
Case / Package SOT-363, SC70
Win Source Part Number 023216-MGA-81563-TR1G
Family Name MGA-81563
Introduction Date April 01, 2004
ECCN 5A991.g
Country of Origin Malaysia, Thailand, Thailand
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-81563-TR1G CAD Model

Description

The Broadcom Limited MGA-81563-TR1G is a high-performance RF amplifier that operates in the frequency range of 100MHz to 6GHz.

  • Frequency Range: 100MHz to 6GHz
  • Gain: 12.3dB
  • Noise Figure: 2.7dB
  • Ideal for: ISM, PCS, PHS, SATCOM, and WLL applications
  • Package: SOT-363, SC70 package
  • Operating Supply Voltage: 2.7V to 3.3V
  • Operating Supply Current: 31mA to 51mA
  • Status: Common-used part with high popularity in the market
  • Supply and Demand Status: Limited
  • Estimated EOL date: Obsolete
