3020-10-0300-00 Real Image
Same model may have multiple batches, images only for reference.

3020-10-0300-00

Part No 3020-10-0300-00
Manufacturer CNC Tech
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 10POS 2.54MM  /  Connector Header Surface Mount 10 position 0.100" (2.54mm)
Datasheet
3020-10-0300-00 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr CNC Tech
Package Tray
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 10
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Insulation Height 0.354" (9.00mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating Flash
Contact Material Brass
Insulation Material Polyamide (PA6T), Nylon 6T; Polyamide (PA9T), Nylon 9T
Features Keying Slot
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 3A (AC/DC)
Base Product Number 3020-10
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 1175-1621,3020-10-0300-00-ND
Standard Package 130
Win Source Part Number 1021923-3020-10-0300-00
Ultra Librarian 3D Model Ultra Librarian 3020-10-0300-00 CAD Model

Description

The 1021923-3020-10-0300-00 is a board to cable/wire connector designed and manufactured by CNC Tech.

  • Connector Type: Board to cable/wire
  • Manufacturer: CNC Tech
  • Pitch: 0.100" (2.54mm)
  • Positions Loaded: 10
  • Rows: 2
  • Keying: Keying slot
  • Shrouding: Shrouded-4 wall
  • Fastening Type: Push-pull
  • Contact Material: Brass
  • Contact Finish: Gold
  • Insulation Material: Polyamide (PA6T), nylon 6T; polyamide (PA9T), nylon 9T
  • REACH: Unaffected
  • Operating Temperature: -40°C to 105°C
