XGL3520-222MEC

Name: XGL3520-222MEC
Brand: Coilcraft
SKU: 1382163
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	XGL3520-222MEC
Manufacturer	Coilcraft
Catalog	Fixed Inductors
Description	FIXED INDUCTOR 2.2UH SMD / 2.2 µH Shielded Molded Inductor 4.2 A 31.8mOhm Max Nonstandard
Datasheet	XGL3520-222MEC Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Coilcraft
Series	XGL3520
Package	Strip
Type	Molded
Material - Core	-
Inductance	2.2 µH
Tolerance	±20%
Current Rating (Amps)	4.2 A
Current - Saturation (Isat)	3.7A
Shielding	Shielded
DC Resistance (DCR)	31.8mOhm Max
Q @ Freq	-
Frequency - Self Resonant	50MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1 MHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max)	0.079" (2.00mm)
REACH Status	Vendor Undefined
ECCN	EAR99
Standard Package	1 pcs
Win Source Part Number	1382163-XGL3520-222MEC
Ultra Librarian 3D Model	Ultra Librarian XGL3520-222MEC CAD Model

Alternative Products

Description

The XGL3520-222MEC is a fixed inductor from Coilcraft. It is part of the XGL3520 series and offers an inductance of 2.2μH.

Inductance: 2.2μH
Height: 0.079" (2.00mm)
Size: 0.138" L x 0.126" W (3.50mm x 3.20mm)
Shielded: Yes
Tolerance: ±20%
Application: AEC-Q200
DC Resistance: 31.8mΩ
Saturation Current: 4.2A
Operating Temperature: -40°C to 125°C
RoHS: Compliant
REACH: Vendor Undefined
