The ST-7TB102 is a trimming potentiometer produced by Copal Electronics Inc. It is designed to facilitate accurate electrical adjustments in a variety of electronic circuits. These potentiometers are prized for their reliability and consistent performance throughout their service life.

Applications

• Calibration of measuring instruments
• Adjustment of feedback loops in power supplies
• Fine-tuning of audio equipment
• Setting bias currents in amplifier circuits
• Precise voltage division

Features

• Compact dimensions for applications where space is limited
• Sealed design to protect against environmental contaminants
• High resolution capability for precise adjustment
• Stable resistance material ensuring long-term reliability
• Availability in diverse resistance values to suit specific needs

Benefits

• Facilitates accurate and repeatable electrical parameter adjustments
• Improves the operational efficiency and stability of electronic systems
• Minimizes the need for frequent recalibration processes
• Prolongs the operational lifespan of the associated equipment
• Delivers a cost-effective solution for precision control implementation

Additional Details

The ST-7TB102 has a through-hole mounting configuration. Its resistance is 1k ohms. It is typically rated for a power dissipation of around 0.25W. The operating temperature range extends from -55°C to +125°C. The mechanical lifespan is designed to withstand a significant number of rotational cycles. The resistive element commonly consists of cermet, which provides excellent stability and precision. Copal Electronics is known for its commitment to quality and reliability. This potentiometer is intended for applications that require precision and dependable adjustment capabilities.

The ST-7TB102 is also commonly employed in applications such as programmable logic controllers (PLCs), motor control systems, and various types of test and measurement equipment. Its robust design and stable performance make it a preferred choice for engineers seeking a reliable trimming potentiometer. Its ability to maintain its characteristics over time and temperature fluctuations makes it particularly valuable in demanding industrial environments.
