Linear Technology LTC4006EGN-2#PBF High Efficiency Standalone Li-Ion Battery Charger

The LTC4006EGN-2#PBF is a highly efficient, standalone battery charger specifically designed for charging lithium-ion batteries. Manufactured by Linear Technology, a leader in analog integrated circuits, this charger is ideal for a wide range of applications, including portable computers, medical and industrial equipment, and battery backup systems. The LTC4006EGN-2#PBF is capable of delivering up to 4A of charge current and is designed for use with up to 6-cell lithium-ion batteries.

One of the key features of the LTC4006EGN-2#PBF is its ability to operate with a wide input voltage range, making it versatile for various power supply conditions. The charger uses a constant-current/constant-voltage algorithm to charge batteries, ensuring a safe and efficient charging process. The final float voltage accuracy is maintained within ±0.5% to ensure the battery is charged to its maximum capacity without overcharging.

The LTC4006EGN-2#PBF also offers a range of safety features that protect both the charger and the battery. These include programmable charge current limiting, an overvoltage protection circuit, and a thermal regulation mechanism to maximize the charge rate without the risk of overheating. Additionally, the charger includes an automatic recharge feature, which initiates a new charging cycle if the battery voltage falls below a preset level.

For ease of integration into various systems, the LTC4006EGN-2#PBF comes in a compact 24-pin SSOP package. The device also offers an optional termination charge timer, a C/10 charge termination indicator, and a charge status output signal, providing valuable feedback and control for the charging process.

In summary, the LTC4006EGN-2#PBF from Linear Technology is a robust and reliable solution for those in need of a high-performance lithium-ion battery charger. Its combination of efficiency, versatility, and safety features makes it an excellent choice for designers looking to incorporate a dependable charging system into their applications.
