The CMPA2060025D is a GaN HEMT (Gallium Nitride High Electron Mobility Transistor) power amplifier designed and manufactured by Cree (now Wolfspeed). This transistor is designed for use in high-performance RF and microwave applications, offering high efficiency, high gain, and excellent ruggedness.

Applications:

• Radar systems
• Communication systems (e.g., cellular base stations)
• Industrial heating and drying
• Test and measurement equipment
• Avionics

Features:

• High Efficiency: GaN technology enables high drain efficiency, reducing power consumption and heat generation.
• High Gain: Provides significant signal amplification, reducing the need for additional amplifier stages.
• Wide Bandwidth: Capable of operating over a broad range of frequencies.
• High Power Density: Delivers significant power output in a compact package.
• Excellent Ruggedness: Designed to withstand high VSWR (Voltage Standing Wave Ratio) conditions, ensuring reliable performance.

Benefits:

• Reduced System Power Consumption: High efficiency minimizes energy usage, leading to lower operating costs.
• Improved System Performance: High gain and wide bandwidth enhance signal quality and range.
• Compact System Design: High power density allows for smaller and lighter system designs.
• Increased System Reliability: Excellent ruggedness ensures consistent performance in harsh operating environments.
• Lower System Cost: Integration of high gain and high efficiency reduces the need for additional components.

Technical Specifications:

The CMPA2060025D typically operates in the 2.0 to 6.0 GHz frequency range. It provides an output power of approximately 25W with a drain efficiency of around 50% or higher. The gain is typically around 12 to 15 dB. The operating voltage is usually around 28 to 50V. It is available in a flange-mount package for efficient heat dissipation. Always refer to the Wolfspeed datasheet for precise specifications.

The Wolfspeed CMPA2060025D is a high-performance GaN HEMT power amplifier offering excellent efficiency, gain, and ruggedness for demanding RF and microwave applications.
