C4D02120E-TR Real Image C4D02120E-TR Real Image1 C4D02120E-TR Real Image2
Same model may have multiple batches, images only for reference.
C4D02120E-TR Real Image C4D02120E-TR Real Image1 C4D02120E-TR Real Image2
C4D02120E-TR Real Image C4D02120E-TR Real Image1 C4D02120E-TR Real Image2
Same model may have multiple batches, images only for reference.

C4D02120E-TR

Part No C4D02120E-TR
Manufacturer Cree/Wolfspeed
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 1.2KV 9A TO252-2 / Rectifier Diode Schottky 1.2KV 9A 3-Pin(2+Tab) TO-252 T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Cree/Wolfspeed
Packaging Reel - TR
Status Active
Diode Type Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 9A
Voltage - Forward (Vf) (Max) @ If 1.8V @ 2A
Speed(Frequency) No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) 0ns
Current - Reverse Leakage @ Vr 50μA @ 1200V
Capacitance @ Vr, F 167pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package TO-252-2
Operating Temperature - Junction -55°C to 175°C
Win Source Part Number 1027367-C4D02120E-TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Portable Devices, Power Management, Industrial
Family Name C4D02120E
Introduction Date September 02, 2015
ECCN EAR99
Country of Origin China, Philippines, United States of America
Estimated EOL Date Not Applicable
Ultra Librarian 3D Model Ultra Librarian C4D02120E-TR CAD Model

Description

The C4D02120E-TR is a Silicon Carbide Schottky diode that comes in a TO-252-2 package from Cree/Wolfspeed.

  • Component: Silicon Carbide Schottky diode
  • Package: TO-252-2
  • Maximum Reverse Voltage: 1200V
  • Average Rectified Current: 9A
  • Forward Voltage: 1.8V @ 2A
  • Reverse Recovery Time: 0ns
  • Capacitance: 167pF @ 0V, 1MHz
  • Current Leakage: 50μA @ 1200V
  • Ideal for: use in portable devices, power management, and industrial applications
  • Temperature Range: -55°C to 175°C
  • Supply and Demand Status: balanced
