Same model may have multiple batches, images only for reference.
CY62146ELL-45ZSXA Real Image
Same model may have multiple batches, images only for reference.

CY62146ELL-45ZSXA

Part No CY62146ELL-45ZSXA
Manufacturer Cypress Semiconductor Corp
Catalog RAM
Description 4-Mbit (256K x 16) Static RAM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Cypress Semiconductor Corp
Series MoBL
Packaging Tray
Memory Type Volatile
Memory Format SRAM
Technology SRAM - Asynchronous
Memory Size 4Mb (256K x 16)
Write Cycle Time - Word, Page 45ns
Access Time 45ns
Memory Interface Parallel
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 44-TSOP (0.400", 10.16mm Width)
Manufacturer Package 44-TSOP II
Win Source Part Number 1164330-CY62146ELL-45ZSXA
Manufacturer Homepage www.cypress.com
Popularity Medium
Supply and Demand Status Limited
Family Name CY62146ELL
Introduction Date October 10, 2001
ECCN 3A991.b.2.a
Country of Origin Taiwan
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian CY62146ELL-45ZSXA CAD Model

Description

The Cypress Semiconductor Corp CY62146ELL-45ZSXA is an obsolete (EOL) electronic component with a limited supply.

  • Type: High-performance asynchronous SRAM
  • Memory Size: 4Mb (256K x 16)
  • Access Time: 45ns
  • Operating Supply Voltage: 4.5 V to 5.5 V
  • Operating Temperature Range: -40°C to 85°C
  • Package: 44-TSOP II
  • Mounting Technology: SMD
