Same model may have multiple batches, images only for reference.
CY7C141-25JXC Real Image
Same model may have multiple batches, images only for reference.

CY7C141-25JXC

Part No CY7C141-25JXC
Manufacturer Cypress Semiconductor Corp
Catalog RAM
Description 1K x 8 Dual-Port Static RAM
Datasheet
CY7C141-25JXC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Cypress Semiconductor Corp
Packaging Tube
Part Status Obsolete(EOL)
Memory Type Volatile
Memory Format SRAM
Technology SRAM - Dual Port, Asynchronous
Memory Size 8Kb (1K x 8)
Write Cycle Time - Word, Page 25ns
Access Time 25ns
Memory Interface Parallel
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range 0°C ~ 70°C (TA)
Mounting SMD
Package 52-LCC (J-Lead)
Manufacturer Package 52-PLCC (19.13x19.13)
Win Source Part Number 1165146-CY7C141-25JXC
Manufacturer Homepage www.cypress.com
Popularity Medium
Supply and Demand Status Limited
Family Name CY7C141
Introduction Date March 31, 1997
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian CY7C141-25JXC CAD Model

Description

The Cypress Semiconductor Corp CY7C141-25JXC is a dual port, asynchronous SRAM memory chip with a volatile memory size of 8Kb (1K x 8).

  • Product Status: Obsolete
  • Estimated EOL Date: Yes
  • Memory Interface: Parallel
  • Package: 52-LCC (J-Lead)
  • Operating Supply Voltage: 4.5 V to 5.5 V
  • Access Time: 25ns
  • Write Cycle Time (Word): 25ns
  • Write Cycle Time (Page): 25ns
  • Package Dimensions: 19.13x19.13 mm
  • Halogen Free: Yes
  • Category: Integrated Circuits (ICs)
  • Memory Format: SRAM
