Products specifications Report Issue?

Manufacturer Dc Components
Win Source Part Number 1167750-DL5242B
Manufacturer Homepage www.dccomponents.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian DL5242B CAD Model

Description

The DL5242B is a 12V, 0.5W Zener diode manufactured by DC Components. It is designed to provide voltage regulation and transient voltage suppression in various electronic circuits. This diode maintains a stable voltage level across its terminals when reverse biased, making it suitable for protecting sensitive components from voltage spikes and providing a stable reference voltage.

Applications:

  • Voltage Regulation: Provides a stable 12V output in power supplies and voltage regulators.
  • Transient Voltage Suppression: Protects sensitive electronic components from voltage spikes and surges.
  • Clipping Circuits: Limits the voltage in signal processing circuits.
  • Overvoltage Protection: Protects circuits from damage due to overvoltage conditions.
  • Reference Voltage: Provides a stable reference voltage for various electronic circuits.

Features:

  • Zener Voltage: 12V Zener voltage.
  • Power Dissipation: 0.5W power dissipation.
  • DO-35 Package: Standard DO-35 package for easy mounting.
  • Low Leakage Current: Minimal leakage current at reverse bias.
  • Stable Voltage: Maintains a stable voltage over a wide temperature range.

Benefits:

  • Voltage Regulation: Provides a stable output voltage, protecting sensitive components.
  • Transient Protection: Protects circuits from damage due to voltage spikes.
  • Easy to Use: Simple to incorporate into electronic circuits.
  • Cost-Effective: Provides a cost-effective solution for voltage regulation and protection.
  • Reliable Operation: Designed for long-term reliability and stable performance.

Additional Details:

The DL5242B is typically used in circuits where a 12V regulated voltage is required. The Zener diode should be used with a series resistor to limit the current through the diode and prevent overheating. The specific value of the series resistor depends on the input voltage and the desired output current. The DO-35 package is a standard through-hole package that is easy to solder onto a PCB. The Zener diode is designed to operate over a wide temperature range, typically from -65°C to +200°C. The datasheet provides detailed information on the electrical characteristics, temperature coefficients, and surge current capabilities of the DL5242B. It is a reliable and cost-effective component for voltage regulation and transient voltage suppression in a variety of electronic applications.
