Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 2.2 V/μs
Gain Bandwidth Product (GBP) 5.5MHz
Current - Input Bias 50nA
Voltage - Input Offset 1mV
Operating Supply Current 2.3mA
Channel Output Current 20mA
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 032211-TJM4558CDT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TJM4558CDT CAD Model

Description

Overview of STMicroelectronics TJM4558CDT

The TJM4558CDT is a high-performance operational amplifier (op-amp) produced by STMicroelectronics, a global leader in semiconductor solutions. This op-amp is designed to offer a perfect balance of features that make it suitable for a wide range of applications, including audio pre-amplification, active filters, and signal conditioning circuits.

Key Features

  • Dual Operational Amplifier: The TJM4558CDT contains two independent op-amps in a single package, providing flexibility and reducing space requirements on PCBs.
  • High Gain Bandwidth: It offers a high gain bandwidth product of 3 MHz, allowing the device to handle a wide range of frequencies with ease.
  • Low Noise: Engineered for low noise operation, this op-amp is an excellent choice for audio applications and other sensitive signal processing tasks.
  • Low Harmonic Distortion: The device is characterized by low harmonic distortion, which is critical for maintaining signal fidelity, especially in high-fidelity audio systems.
  • Large Output Voltage Swing: The TJM4558CDT can swing close to the supply rails, maximizing the dynamic range of the output signal.
  • Wide Supply Voltage Range: It can operate with a supply voltage range from 3V to 30V, accommodating a variety of power supply configurations.

Applications

The versatility of the TJM4558CDT makes it suitable for a broad array of applications. It is commonly used in:

  • Audio processing equipment
  • Active filters
  • Voltage followers
  • Integrators or differentiators
  • DC amplification blocks

Package and Quality

The TJM4558CDT is packaged in a compact and reliable SO-8 package, which is well-suited for space-constrained applications. STMicroelectronics ensures high standards of quality and reliability for their products, and the TJM4558CDT is no exception, undergoing rigorous testing and quality control measures.

Overall, the TJM4558CDT from STMicroelectronics stands out as a robust, high-performance operational amplifier that can enhance the performance and efficiency of a wide range of electronic systems.
