Product Overview: 1N5819HW-7 Schottky Barrier Rectifier

The 1N5819HW-7 is a high-efficiency, surface-mount Schottky Barrier Rectifier designed by Diodes Incorporated, a leading manufacturer and supplier of high-quality semiconductor products. This rectifier is tailored for applications requiring low voltage, high frequency rectification, or as a freewheeling and polarity protection diode.

Key Features

• Low Forward Voltage Drop: With a maximum forward voltage drop of 0.550V at 1A, this diode ensures high efficiency in its operation, making it suitable for use in low voltage, high power density applications.
• High Current Capability: The 1N5819HW-7 can handle a high forward surge current of 25A, which is beneficial for applications that experience surges or spikes in current.
• Power Dissipation: Rated at 0.5W, this device can dissipate a moderate amount of power, contributing to its overall reliability and longevity.
• Low Thermal Resistance: Its low thermal resistance allows for better heat dissipation, ensuring the diode operates within its safe temperature range even under high current conditions.
• Surface Mount Package: The device comes in a SOD-123F package which is compact and suitable for automated assembly processes, saving space on the PCB and reducing manufacturing costs.

Applications

The 1N5819HW-7 is ideal for a wide range of applications, including:

• Switching power supplies
• Converters
• Free-wheeling diodes in power management
• Reverse battery protection
• DC-DC converters
• Automotive applications

Environmental and Quality Certifications

Diodes Incorporated ensures that the 1N5819HW-7 meets rigorous environmental and quality standards. The device is lead-free, halogen-free, and RoHS compliant, minimizing the environmental impact and making it suitable for eco-friendly applications. Additionally, it is characterized for operation from -65°C to 125°C, providing reliable performance across a wide range of temperature conditions.

Conclusion

In summary, the 1N5819HW-7 from Diodes Incorporated is a robust, versatile Schottky Barrier Rectifier that provides designers with a highly efficient and reliable component for their power management solutions. Its compact form factor, high current capability, and low power loss make it an excellent choice for modern electronic applications.
