Product Overview: 1SMB5924B-13 by Diodes Incorporated

The 1SMB5924B-13 from Diodes Incorporated is a robust surface-mount Zener diode designed for applications requiring voltage regulation and transient voltage protection. This precision Zener diode offers a nominal Zener voltage of 13V with a tolerance of ±5%, making it ideal for use in a wide range of electronic circuits where stable voltage is crucial.

Key Features

• Zener Voltage (V_Z): 13V
• Zener Voltage Tolerance: ±5%
• Power Dissipation: 1.5W, allowing for good thermal performance in a small package size.
• Package: SMB (DO-214AA), a surface-mount package that is both compact and rugged, suitable for automated assembly processes and high-density circuit boards.
• Operating and Storage Temperature Range: -55°C to +150°C, ensuring reliability over a wide range of environmental conditions.

Applications

The 1SMB5924B-13 is versatile and can be used in a variety of applications, including:

• Power supply circuits
• Consumer electronics
• Automotive systems
• Industrial equipment
• Telecommunication infrastructure

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the 1SMB5924B-13 is no exception. It is manufactured in compliance with the stringent industry standards, ensuring high reliability and performance. The device also features a low dynamic impedance and is capable of withstanding surge currents, making it an excellent choice for protecting sensitive electronic components from voltage spikes and transients.

Environmental Compliance

The 1SMB5924B-13 is lead-free and RoHS compliant, reflecting Diodes Incorporated's dedication to environmental responsibility. This commitment ensures that the product is suitable for use in applications where environmental regulations are a concern.

In summary, the 1SMB5924B-13 Zener diode from Diodes Incorporated is an exceptional component for designers looking for a reliable and precise voltage regulation solution that meets the demands of modern electronic devices.
