Product Overview: 74LVC2G86HD4-7 Dual 2-Input EXCLUSIVE-OR Gate

The 74LVC2G86HD4-7 is a high-performance, dual 2-input EXCLUSIVE-OR gate integrated circuit from Diodes Incorporated, designed to operate in a wide voltage range with low power consumption. This IC is part of the 74LVC family, which is known for its low-voltage operation and compatibility with TTL levels, making it ideal for interfacing with both 3.3V and 5V systems.

Key Features:

• Logic Type: EXCLUSIVE-OR (XOR) Gate
• Number of Circuits: Dual 2-Input
• Supply Voltage Range: 1.65V to 5.5V
• Logic Level Compatibility: LVTTL, LVCMOS
• High-Speed Operation: Up to 100 MHz (6.5ns propagation delay)
• Output Current: ±24 mA
• Package: 8-TSSOP, 8-MSOP, 8-SOIC
• Operating Temperature Range: -40°C to +125°C
• RoHS Compliant: Yes

Performance Advantages:

The 74LVC2G86HD4-7 is designed for optimal performance in digital signal processing and complex logic functions. With its fast switching speeds and low power dissipation, this IC is suitable for high-speed data processing applications. Its wide operating voltage range allows for flexible integration into various system designs without the need for level shifting.

Applications:

Due to its versatile nature, the 74LVC2G86HD4-7 can be used in a broad array of applications. It is particularly useful in:

• High-speed data processing systems
• Networking equipment
• Portable devices
• Computing peripherals
• Telecommunication systems
• Consumer electronics

Quality and Reliability:

Diodes Incorporated ensures that the 74LVC2G86HD4-7 meets stringent quality standards, providing reliable performance in industrial and commercial applications. The device is also RoHS compliant, ensuring adherence to environmental regulations concerning hazardous substances.

Overall, the 74LVC2G86HD4-7 from Diodes Incorporated is a high-quality component that offers designers a compact, efficient, and reliable solution for implementing EXCLUSIVE-OR logic functions in a wide range of electronic systems.
