Product Overview: AP2114HA-2.5TRG1

The AP2114HA-2.5TRG1 is a highly reliable, low dropout linear regulator designed and manufactured by Diodes Incorporated. This component is specifically engineered to deliver a stable and precise 2.5V output voltage, making it an ideal choice for a wide array of electronic applications that require consistent power regulation.

Key Features

• Output Voltage: The device provides a fixed output voltage of 2.5V, suitable for powering sensitive electronic circuits.
• High Output Accuracy: It ensures high accuracy in output voltage regulation, which is crucial for maintaining the performance of the end application.
• Low Dropout: With a low dropout performance, the AP2114HA-2.5TRG1 can maintain output voltage regulation even with a minimal difference between the input and output voltages.
• Current Capacity: It offers a maximum output current of up to 1A, ensuring sufficient power for a range of devices.
• Thermal Protection: The built-in thermal shutdown function provides protection against excessive temperature rises, enhancing the reliability of the device.
• Short Circuit Protection: The regulator includes short circuit protection to safeguard the electronic components in case of a fault condition.
• Low Power Consumption: Designed for energy efficiency, the AP2114HA-2.5TRG1 has a low quiescent current, which minimizes power consumption when in operation.
• Package Format: Available in a Green SOT-25 package, it is both compact and environmentally friendly.

Applications

The AP2114HA-2.5TRG1 is versatile and can be used in various applications, including but not limited to:

• Portable Devices
• Battery-Powered Equipment
• Microprocessors and DSPs Supply
• Consumer Electronics
• Wireless Communication Devices

With its combination of high accuracy, reliability, and power efficiency, the AP2114HA-2.5TRG1 from Diodes Incorporated stands out as a superior choice for designers seeking a linear voltage regulator that meets stringent power requirements while maintaining a compact footprint.
