The AP2204K-ADJTRG, manufactured by Diodes Incorporated, is a high-performance, low dropout linear regulator designed to deliver a continuous adjustable output voltage with a high level of accuracy and stability. This component is particularly suitable for battery-powered devices, portable equipment, and other applications where an efficient power management solution is essential.

Key Features

• Adjustable Output Voltage: The regulator provides an adjustable output voltage range, which can be finely tuned to meet the specific requirements of your application, ensuring flexibility and precision in a wide array of devices.
• Low Dropout Performance: With its low dropout capability, the AP2204K-ADJTRG maintains regulation even when the input voltage is very close to the output voltage, which enhances efficiency and prolongs battery life in portable applications.
• High Output Accuracy: This regulator offers excellent output voltage accuracy, which is critical for sensitive electronic circuits, ensuring reliable operation and consistent performance.
• Thermal Protection: The built-in thermal protection feature prevents the device from overheating, enhancing the reliability and longevity of both the regulator and the overall system.
• Current Limit Protection: The AP2204K-ADJTRG includes current limit protection to safeguard the device and the load from damage due to excessive current conditions.
• Low Quiescent Current: It features a low quiescent current that minimizes standby power consumption, making it ideal for power-sensitive applications.

Applications

The AP2204K-ADJTRG is versatile and can be used in various applications, including:

• Mobile Phones and PDAs
• Laptop and Notebook Computers
• Portable Media Players
• Wireless LAN Devices
• GPS Systems

Package and Availability

This regulator is available in a compact SOT-25 package, which is suitable for space-constrained applications. The AP2204K-ADJTRG is distributed in tape and reel format, facilitating efficient assembly during the manufacturing process.

For detailed specifications, application notes, and additional resources, please refer to the official datasheet provided by Diodes Incorporated or contact their support for technical assistance.
