The AP2552W6-7 is a high-performance, precision integrated circuit from Diodes Incorporated, designed to provide efficient power distribution and management within electronic systems. This advanced power switch is specifically engineered to cater to USB and other hot-swap applications, ensuring devices operate safely and reliably when connecting or disconnecting from a power source.

Key Features

• Integrated Load Switch: The AP2552W6-7 features an integrated load switch that allows for controlled power-up and power-down, minimizing inrush current and protecting downstream circuits.
• Programmable Current Limit: Users can set a precise current limit to avoid damage to the USB port or other interfaces due to overcurrent conditions.
• Fast Short-Circuit Response: The device responds quickly to short-circuit conditions, enhancing the protection of the system.
• Thermal Shutdown Protection: With built-in thermal shutdown, the AP2552W6-7 prevents overheating, ensuring the longevity and stability of the system.
• Low RDS(ON): The low on-resistance of the internal switch ensures minimal voltage drop and power loss, making it ideal for high-efficiency applications.

Applications

• USB peripherals and hubs
• Hot-swap supplies
• Portable consumer electronics
• Computing and network systems

Product Specifications

The AP2552W6-7 is packaged in a small 6-pin SOT-26 package, making it suitable for space-constrained applications. It operates over a wide input voltage range and is capable of handling continuous current up to a specified limit. The precision of the current limit ensures that the AP2552W6-7 can be used in sensitive applications where the exact current control is critical.

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the AP2552W6-7 is no exception. It is manufactured to the highest industry standards, ensuring reliable performance in a wide range of operating conditions. The device has also undergone rigorous testing to guarantee its functionality and durability.
