The AP7350-25CF4-7 is a high-performance, low dropout regulator from Diodes Incorporated, designed to deliver a continuous output current of up to 150mA. This regulator is specifically tailored for portable and battery-powered applications where efficiency and compact size are crucial.

Key Features

• Output Voltage: This device provides a fixed output voltage of 2.5V, which is ideal for powering sensitive electronic components requiring a stable power supply.
• High Accuracy: The output voltage accuracy is maintained within ±1%, ensuring reliable performance and suitability for precision applications.
• Low Dropout: With its low dropout feature, the AP7350-25CF4-7 can maintain regulation with a minimal difference between the input and output voltages, thereby enhancing efficiency and battery life.
• Low Quiescent Current: The device boasts a low quiescent current of just 1µA in shutdown mode, which significantly reduces power consumption when the device is not active.
• Current Limit Protection: To safeguard the electronic components, the regulator is equipped with current limit protection that prevents damage due to overcurrent conditions.
• Thermal Shutdown: The built-in thermal shutdown feature ensures the device operates within safe temperature ranges, providing additional protection against overheating.

Applications

The AP7350-25CF4-7 is versatile and can be used in a wide range of applications, including:

• Battery-powered devices
• Portable electronics
• Smart wearables
• Medical devices
• Power management for IoT devices

Package and Availability

The regulator comes in a compact SOT-25 package, which is suitable for space-constrained applications. The AP7350-25CF4-7 is part of Diodes Incorporated's commitment to providing power management solutions that combine efficiency with miniaturization, making it an excellent choice for designers looking to optimize their power supply architecture.
