Product Overview: AZ1117H-5.0TRE1

The AZ1117H-5.0TRE1, from Diodes Incorporated, is a high-performance low-dropout (LDO) voltage regulator designed to deliver a fixed output voltage of 5.0V with a current up to 1A. This regulator is an ideal choice for a wide range of applications requiring a stable and reliable power supply.

Key Features

• Output Voltage: Provides a precise 5.0V output, essential for sensitive electronic components that require a stable voltage supply.
• High Current Capability: Capable of delivering up to 1A of output current, making it suitable for powering a variety of devices including microcontrollers, sensors, and analog circuits.
• Low Dropout Voltage: Features a low dropout performance, ensuring efficient operation even when the input voltage is close to the output voltage.
• Thermal Protection: Includes an over-temperature shutdown mechanism that prevents damage from overheating, enhancing the longevity of both the regulator and the device it powers.
• Current Limiting: Equipped with current limit features to protect the device against short-circuit and overload conditions.
• Package: Available in a TO-252 package, which is suitable for surface-mount technology (SMT) and offers a compact footprint for space-constrained applications.

Applications

The AZ1117H-5.0TRE1 is versatile and can be used in a variety of electronic devices. It is particularly useful in:

• Consumer Electronics: Such as set-top boxes, gaming consoles, and personal media players.
• Telecommunication Devices: Like mobile phones, routers, and RF modems.
• Computer Peripherals: Including printers, keyboards, and mice.
• Portable Devices: Such as digital cameras, GPS units, and portable media players.

Reliability and Performance

With its robust design, the AZ1117H-5.0TRE1 ensures a reliable power supply for your electronic devices. Its built-in protection features and efficient operation make it a dependable choice for designers looking to enhance system stability and extend product life. Manufactured by Diodes Incorporated, a leading company in the semiconductor market, this voltage regulator is a testament to high-quality engineering and performance.

For detailed specifications and application notes, it is recommended to consult the datasheet provided by Diodes Incorporated to ensure proper usage and integration into your projects.
