DMN2046U-7

Part No DMN2046U-7
Manufacturer Diodes Incorporated
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 3.4A SOT23
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 3.4A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.4V @ 250μA
Max Gate Charge 3.8nC @ 4.5V
Max Input Capacitance 292pF @ 10V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 760mW (Ta)
Maximum Rds On at Id,Vgs 72 mOhm @ 3.6A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 1033726-DMN2046U-7
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DMN2046U-7 CAD Model

Description

DMN2046U-7 MOSFET by Diodes Incorporated

The DMN2046U-7 is a high-performance, N-Channel enhancement mode Field Effect Transistor (FET) designed by Diodes Incorporated, a leading manufacturer in the semiconductor industry. This MOSFET is a testament to the company's commitment to providing energy-efficient and compact solutions for electronic applications.

Key Features:

  • Low On-Resistance: The DMN2046U-7 boasts an incredibly low on-resistance (RDS(on)), which translates to less energy loss as heat and improved overall efficiency in electronic circuits.
  • High-Speed Switching: With its fast switching capabilities, this MOSFET is ideal for high-speed applications, ensuring minimal delay in electronic signal transmission and processing.
  • Low Threshold Voltage: The device operates at a low threshold voltage, making it suitable for low-voltage applications and enabling it to be driven by logic-level voltages.
  • Surface-Mount Package: Encased in a small SOT-23 package, the DMN2046U-7 is perfect for space-constrained applications, allowing for high-density PCB layouts.
  • Lead-Free and RoHS Compliant: In line with environmental standards, this product is manufactured without the use of lead and complies with the Restriction of Hazardous Substances (RoHS) directive.

Applications:

The DMN2046U-7 is versatile and can be used across various applications, including:

  • Power Management
  • Load Switch
  • DC-DC Converters
  • Battery Management Systems
  • Motor Drives
  • Computing and Storage Platforms

With its compact design and superior electrical characteristics, the DMN2046U-7 is an excellent choice for designers seeking to optimize their power management systems, reduce footprint, and achieve higher efficiency. Diodes Incorporated ensures that this MOSFET meets the rigorous demands of modern electronic devices, making it a reliable component in both consumer and industrial applications.

For detailed specifications, application notes, and additional resources, engineers and designers are encouraged to consult the official datasheet and product documentation provided by Diodes Incorporated.
