DMP4051LK3-13

Part No DMP4051LK3-13
Manufacturer Diodes Incorporated
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 40V 7.2A DPAK / Trans MOSFET P-CH 40V 7.2A 3-Pin(2+Tab) DPAK T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 7.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 14nC @ 10V
Max Input Capacitance 674pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.14W (Ta)
Maximum Rds On at Id,Vgs 51 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252-3
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 050868-DMP4051LK3-13
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name DMP4051LK3
Introduction Date July 17, 2009
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian DMP4051LK3-13 CAD Model

Description

DMP4051LK3-13 from Diodes Incorporated is listed in the Transistors - FETs, MOSFETs - RF category and is typically evaluated by engineers for switching or RF-related circuit designs where compact semiconductor devices are required. This part is relevant for teams supporting communications hardware, signal path designs, power control blocks, and maintenance of existing boards that call for a manufacturer-specific MOSFET. Its value is often tied to design continuity, sourcing precision, and fit within established Diodes Incorporated supply chains rather than broad substitute assumptions. Because the current lifecycle status is unknown, engineers and procurement teams should treat it as a part requiring verification before locking it into new production designs. RoHS compliance information is not available in the provided data, so environmental compliance should also be confirmed through the latest official datasheet, manufacturer declaration, or authorized distributor documentation. For repair, sustainment, and controlled procurement, DMP4051LK3-13 should be sourced with documentation review and traceability in mind.
