Diodes Incorporated PI3EQXDP1201ZBE Product Overview

The PI3EQXDP1201ZBE from Diodes Incorporated is a high-performance, PCIe 3.0 signal ReDriver with linear equalization that enhances signal integrity by conditioning the signals in high-speed interfaces. This product is a critical component designed to ensure the integrity of data transmission in a variety of applications, including desktops, laptops, servers, workstations, and embedded systems.

Key Features

• Protocol Support: The device supports PCI Express 3.0 (8 GT/s) but is also backward compatible with PCIe 2.0 and PCIe 1.1, making it a versatile solution for different PCIe generations.
• Channel Configuration: It features a single-channel configuration that operates at 8.0 GT/s, 5.0 GT/s, and 2.5 GT/s data rates, providing flexibility for various data rate requirements.
• Integrated Equalization: With built-in linear equalization, the PI3EQXDP1201ZBE can compensate for inter-symbol interference (ISI), thereby enhancing signal quality over long PCB traces or cables.
• Low Power Consumption: The device is designed for power efficiency, which is critical for battery-powered applications and helps in reducing the overall system power budget.
• Adjustable Settings: It offers programmable receiver equalization, transmitter amplitude, and flat gain, allowing optimization for specific channel conditions.
• Package: The PI3EQXDP1201ZBE comes in a space-saving 3mm x 3mm, 16-pin TQFN package, suitable for compact designs.

Applications

This ReDriver is ideally suited for applications that require reliable, high-speed data transfer. Common applications include:

• High-performance computing platforms
• Data storage and servers
• Networking and communications equipment
• Consumer electronics such as gaming consoles and VR systems

Quality and Reliability

Diodes Incorporated ensures that the PI3EQXDP1201ZBE meets the highest quality and reliability standards. The device is designed with robust electrostatic discharge (ESD) protection and has undergone rigorous testing to guarantee performance under various conditions.

With its advanced features and reliable performance, the PI3EQXDP1201ZBE is an excellent choice for designers looking to enhance signal integrity in high-speed PCIe interfaces.
