The ZVN3320FTA is a high-performance, N-Channel Enhancement Mode Vertical DMOS FET manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality application-specific standard products within the broad discrete, logic, analog, and mixed-signal semiconductor markets. This MOSFET is designed to deliver efficient performance in a variety of applications, offering a unique combination of features that enhance system reliability and efficiency.

Key Features

• Low On-Resistance: The ZVN3320FTA boasts an exceptionally low on-resistance, which translates into reduced conduction losses and improved overall efficiency in electronic circuits.
• High-Speed Switching: Engineered for fast switching applications, this MOSFET is capable of operating at high frequencies, making it ideal for power management and conversion systems.
• Low Threshold Voltage: With a low gate threshold voltage, the ZVN3320FTA can be easily driven by logic-level voltages, facilitating its use in low-voltage control circuits.
• Surface Mount Package: Packaged in an SOT-23 format, this compact, three-pin device is suited for space-constrained applications and allows for efficient automated assembly.

Applications

The versatility of the ZVN3320FTA enables its use across a diverse range of applications. It is particularly well-suited for:

• Power management in portable and battery-powered devices
• DC-DC converters and power supply circuits
• Motor control systems
• Load/relay drivers
• Switching regulators

Product Specifications

The ZVN3320FTA operates with a continuous drain current of 90mA and a power dissipation of 1.25W. Its drain-source voltage (Vds) is rated at 200V, which allows for handling of higher voltage applications. The device's thermal characteristics are also designed for optimal performance, with a junction temperature range from -55°C to +150°C, ensuring stability and reliability even under extreme operating conditions.

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products that meet the stringent requirements of the electronic industry. The ZVN3320FTA is no exception; it is fabricated with the highest standards to ensure consistent performance and longevity. Customers can rely on this MOSFET for their critical design needs.
