Product Overview

The ZXCT1107SA-7 is a high-performance, low-power current monitor from Diodes Incorporated, designed to provide accurate current sensing solutions for a wide range of applications. This device is particularly well-suited for power management systems, battery chargers, and other electronic circuits where precise current measurement is critical for performance and efficiency.

Key Features

• High Accuracy: The ZXCT1107SA-7 offers excellent accuracy in current sensing, which is essential for maintaining system reliability and performance.
• Low Power Consumption: With its design focused on energy efficiency, this current monitor helps reduce the overall power consumption of the system, making it ideal for battery-powered applications.
• Wide Input Voltage Range: It operates over a broad input voltage range, providing flexibility in various operating conditions and making it suitable for diverse applications.
• Compact SOT23 Package: Housed in a small SOT23 package, the ZXCT1107SA-7 is perfect for space-constrained designs, allowing for a more compact overall footprint.
• Output Voltage Scaling: The output of the ZXCT1107SA-7 is directly proportional to the sensed current, allowing for easy scaling and integration with analog-to-digital converters (ADCs) or microcontrollers for further processing.

Applications

The versatility of the ZXCT1107SA-7 makes it an excellent choice for a variety of applications, including:

• Power supply monitoring
• Battery management systems
• Overcurrent protection circuits
• Portable electronic devices
• Energy management systems

Technical Specifications

The technical specifications of the ZXCT1107SA-7 ensure its adaptability and performance in demanding environments:

• Supply Voltage Range: 2.5V to 20V
• Output Voltage: Proportional to AC or DC currents
• Operating Temperature Range: -40°C to +105°C
• Packaging: SOT23-3

With its combination of accuracy, low power consumption, and compact form factor, the ZXCT1107SA-7 from Diodes Incorporated is an excellent choice for designers looking for a reliable current sensing solution.
