Same model may have multiple batches, images only for reference.
MPSA06BK Real Image
Same model may have multiple batches, images only for reference.

MPSA06BK

Part No MPSA06BK
Manufacturer DIOTEC Electronics Corporation
Catalog RF Transistors (BJT)
Description TRANS NPN 80V 0.5A TO92  /  Bipolar (BJT) Transistor NPN 80 V 500 mA 100MHz 625 mW Through Hole TO-92
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - Bipolar (BJT) - Single
Mfr Diotec Semiconductor
Package Strip
Transistor Type NPN
Current - Collector (Ic) (Max) 500 mA
Voltage - Collector Emitter Breakdown (Max) 80 V
Vce Saturation (Max) @ Ib, Ic 250mV @ 10mA, 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA, 1V
Power - Max 625 mW
Frequency - Transition 100MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package TO-92
Other Names 2721-MPSA06BK
Standard Package 30
Win Source Part Number 1112148-MPSA06BK
Ultra Librarian 3D Model Ultra Librarian MPSA06BK CAD Model

Description

The Diotec Semiconductor MPSA06BK is an NPN bipolar transistor that is ideal for use in a wide range of electronic circuits.

  • Package: TO-92
  • Maximum Power Rating: 625mW
  • Voltage Breakdown: 80V
  • Maximum Collector Current: 500mA
  • Frequency Transition: 100MHz
