Z1SMA24

Name: Z1SMA24
Brand: DIOTEC Electronics Corporation
SKU: 700009
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	Z1SMA24
Manufacturer	DIOTEC Electronics Corporation
Catalog	Diodes - Zener - Single
Description	DIODE ZENER 24V 1W DO214AC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr	DIOTEC Electronics Corporation
Package	Tape & Reel
Product Status	Active
Voltage - Zener (Nom) (Vz)	24 V
Tolerance	±5%
Power - Max	1 W
Impedance (Max) (Zzt)	28 Ohms
Current - Reverse Leakage @ Vr	1 µA @ 18 V
Voltage - Forward (Vf) (Max) @ If	1 V @ 200 mA
Temperature Range - Operating	-50°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Standard Package	7,500 pcs
MSL Level	1 (Unlimited)
HTSUS	8541.10.0000
Win Source Part Number	700009-Z1SMA24
Ultra Librarian 3D Model	Ultra Librarian Z1SMA24 CAD Model

Alternative Products

Description

The 700009-Z1SMA24 is a single Zener diode designed for discrete semiconductor applications.

Packaging: Tape and reel format
Power Rating: 1W
Tolerance: ±5%
Forward Voltage: 1V @ 200mA
Reverse Leakage Current: 1μA @ 18V
Nominal Zener Voltage: 24V
Impedance: 28 Ohms
Mounting: Surface mountable
Package: DO-214AC, SMA
Operating Temperature Range: -50°C to 150°C
Product Status: Active
Manufacturer: DIOTEC Electronics Corporation
