The PKB4610PINBLA is a DC-DC converter module designed by Ericsson Power Modules. It's a point-of-load (POL) converter, converting a higher voltage to a lower voltage required by a specific component or circuit. These modules are designed for high efficiency and compact size.

Applications:

• Telecommunications Equipment
• Networking Devices
• Data Processing
• Industrial Automation
• Embedded Systems

Features:

• High Efficiency: Minimizes power loss and heat generation.
• Wide Input Voltage Range: Operates from various supply voltages.
• Adjustable Output Voltage: Allows customization to specific load requirements.
• Remote On/Off Control: Enables system-level power management.
• Over-Current Protection (OCP): Protects the module and load from excessive current.
• Over-Temperature Protection (OTP): Prevents damage from overheating.
• Under-Voltage Lockout (UVLO): Ensures proper startup and shutdown.
• Compact Size: Allows for placement near the load, reducing noise and improving transient response.

Benefits:

• Reduced Energy Consumption: High efficiency translates to lower operating costs.
• Flexible System Design: Adjustable output voltage accommodates diverse applications.
• Simplified Power Management: Remote control simplifies system integration.
• Enhanced System Reliability: Protection features prevent damage from common faults.
• Space-Saving Design: Compact size enables higher density board layouts.

Technical Specifications:

The PKB4610PINBLA typically has an input voltage range of 4.5V to 14V and provides an adjustable output voltage, usually between 0.6V and 5.5V, with a maximum output current of up to 10A. The module's efficiency is often around 90% or higher under typical load conditions. It incorporates over-current, over-temperature, and under-voltage lockout protection features. The dimensions of the module are optimized for space-constrained applications. It adheres to industry safety standards and is RoHS compliant. It's designed to operate within a specific temperature range, suitable for industrial and telecom environments. Specific internal components are chosen to maximize reliability and longevity.
