FAN1117ASX Real Image FAN1117ASX Real Image
Same model may have multiple batches, images only for reference.
FAN1117ASX Real Image FAN1117ASX Real Image
FAN1117ASX Real Image FAN1117ASX Real Image
Same model may have multiple batches, images only for reference.

FAN1117ASX

Part No FAN1117ASX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 1.25V to 18V 1A 4-Pin(3+Tab) SOT-223 T/R / IC REG LDO ADJ 1A SOT223-3
Datasheet
FAN1117ASX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 18V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 18V
Dropout Voltage-Max 1.2V @ 1A
Output Current 1A
Operating Supply Current 13mA
PSRR 72dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 18 V
Voltage - Dropout (Typical) 1.1V @ 1A
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 066747-FAN1117ASX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Consumer Electronics, Automotive, Power Management, Motor Drive & Control
Family Name FAN1117A
Introduction Date April 27, 2001
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian FAN1117ASX CAD Model

Description

Product Overview

The FAN1117ASX is a standard low dropout voltage regulator, delivering reliable performance for a range of voltage regulation applications.

Features and Benefits

  • Standard Voltage Output: Offers adaptability across various electronic projects.
  • Highly Efficient: Minimizes power loss and heat dissipation.
  • Protective Features: Equipped with internal current limiting and thermal shutdown capabilities.

Applications

  • Consumer Appliances
  • Data Processing Equipment
  • Portable Instruments
