FAN3100TSX

Name: FAN3100TSX
Brand: Fairchild/ON Semiconductor
SKU: 452673
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FAN3100TSX
Manufacturer	Fairchild/ON Semiconductor
Catalog	PMIC - Gate Drivers
Description	IC GATE DRVR SGL TTL 2A SOT23-5
Datasheet	FAN3100TSX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Driven Configuration	Low-Side
Channel Type	Single
Number of Drivers	1
Gate Type	N-Channel MOSFET
Supply Voltage - Operating	4.5 V to 18 V
Logic Voltage - VIL, VIH	0.8V, 2V
Current - Peak Output (Source, Sink)	3A, 3A
Input Type	Inverting, Non-Inverting
Rise and Fall Time	13ns, 9ns
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-5
Win Source Part Number	1037627-FAN3100TSX
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	FAN3100
Introduction Date	October 01, 2007
ECCN	EAR99
Country of Origin	Philippines, Taiwan, Thailand
Halogen Free	Compliant
Estimated EOL Date	2025
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian FAN3100TSX CAD Model

Alternative Products

Description

The FAN3100TSX is a single channel low-side gate driver IC designed for driving N-channel MOSFETs in low-side switching applications manufactured by Fairchild/ON Semiconductor.

Peak Source Current: up to 3A
Peak Sink Current: up to 3A
Input: inverting or non-inverting
Logic Voltage: 0.8V to 2V
Supply Voltage: 4.5V to 18V
Rise Time: 13ns
Fall Time: 9ns
Package: SOT-23-5
Compliance: halogen-free requirements
