FDC6506P

Part No FDC6506P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2P-CH 30V 1.8A SSOT6
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
FET Type 2 P-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 1.8A
Maximum Rds On at Id,Vgs 170 mOhm @ 1.8A, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 3.5nC @ 10V
Max Input Capacitance 190pF @ 15V
Maximum Power Dissipation 700mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SuperSOT-6
Win Source Part Number 015924-FDC6506P
Family Name FDC6506P
Introduction Date March 17, 1999
ECCN EAR99
Country of Origin Israel, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDC6506P CAD Model

Description

FDC6506P from Fairchild/ON Semiconductor is listed in the Transistors - FETs, MOSFETs - RF category and is typically considered for switching or signal-handling roles in compact electronic designs where MOSFET performance, board space, and sourcing continuity matter. Engineers may evaluate this device for RF-adjacent circuits, portable equipment, communication hardware, and supporting power or signal path functions, depending on the exact design requirements in the official datasheet. Its value is tied to brand familiarity, broad market recognition, and potential fit in legacy or maintenance-driven designs that still reference Fairchild or ON Semiconductor devices. The current lifecycle status is information not available, so teams should confirm whether the part is active, obsolete, or subject to allocation before committing it to new production. RoHS compliance information is also not available in the provided data and should be verified directly through manufacturer documentation, distributor compliance records, or the latest product datasheet before procurement or regulatory use.
