FDD4243 Real Image FDD4243 real image4048 FDD4243 real image4049 FDD4243 Real Image1 FDD4243 Real Image2 FDD4243 Real Image3 FDD4243 Real Image4 FDD4243 Real Image5 FDD4243 Real Image6 FDD4243 Real Image7
Same model may have multiple batches, images only for reference.
FDD4243 Real Image FDD4243 real image4048 FDD4243 real image4049 FDD4243 Real Image1 FDD4243 Real Image2 FDD4243 Real Image3 FDD4243 Real Image4 FDD4243 Real Image5 FDD4243 Real Image6 FDD4243 Real Image7
FDD4243 Real Image FDD4243 real image4048 FDD4243 real image4049 FDD4243 Real Image1 FDD4243 Real Image2 FDD4243 Real Image3 FDD4243 Real Image4 FDD4243 Real Image5 FDD4243 Real Image6 FDD4243 Real Image7
Same model may have multiple batches, images only for reference.

FDD4243

Part No FDD4243
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH Si 40V 6.7A 3-Pin(2+Tab) DPAK T/R / MOSFET P-CH 40V 6.7A DPAK
Datasheet
FDD4243 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 6.7A (Ta), 14A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 29nC @ 10V
Max Input Capacitance 1550pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 42W (Tc)
Maximum Rds On at Id,Vgs 44 mOhm @ 6.7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 015940-FDD4243
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 2,500
Family Name FDD4243
Introduction Date September 28, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian FDD4243 CAD Model

Description

FDD4243 Overview

The FDD4243 is a versatile N-channel MOSFET designed for medium power applications. It is ideal for use in motor drives and telecom equipment due to its balanced performance and efficiency.

Features and Benefits

  • Optimized design for thermal performance
  • Enhanced reliability under high stress conditions
  • Cost-effective solution with excellent durability

Applications

  • Motor control circuits
  • Battery management systems
  • Power tools
  • Telecommunication power management

Additional Details: With its rugged design, the FDD4243 offers improved reliability and efficiency in harsh conditions.
